- Load per castor75kg *
- Wheel diameter75mm
- Overall height100mm
- WheelPolypropylene
- Secure checkout
- 14-day returns on unused items
- UK-based castor advice
Specifications
- Castor Type
- Swivel Top Plate Castor
- Wheel Diameter
- 75mm
- Wheel Material
- Polypropylene
- Wheel Colour
- Black
- Tread Width
- 22mm
- Bearing Type
- Plain
- Load Capacity
- 75kg *
- Plate Length
- 60mm
- Plate Width
- 60mm
- Plate Hole Centres Length
- 48/38mm
- Plate Hole Centres Width
- 48/38mm
- Plate Hole Diameter
- 6mm
- Swivel Radius
- 70mm
- Total Castor Height
- 100mm
Will it fit?
- Top plate60mm × 60mm
- Hole centres48/38mm × 48/38mm
- Fixing holeØ 6mm
- Overall height100mm
- Swivel radius70mm
Replacing an old castor? Measure between the centres of two fixing holes along the long edge, then across the short edge, and compare with the hole centres above. Allow the swivel radius as clear space around each castor so it can turn freely.
Load check
How we work it out: on a real floor one castor is often carrying little or nothing, so we share the weight across one fewer castor than you fit (with 3 castors, across all 3). Tick the box to add a 30% margin for rough use.
Floors & use
Nylon / polypropylene wheel
- Very easy to push, even when loaded
- Resists water, oil and many chemicals
- Hard-wearing and easy to wipe clean
- Best on smooth concrete and hard floors
- Noisier than rubber or polyurethane
- Hard tread can mark or damage soft and delicate floors
- Rolls poorly over debris and cables
Details & FAQs
Light Duty Top Plate Castors
This 75mm swivel castor with a black polypropylene wheel is a dependable choice for shop fitters and all kinds of mobile units. It carries up to 75kg per castor and its swivel design makes it easy to steer around tight spaces, helping to reduce manual strain and keep work flowing.
With a lightweight yet durable polypropylene wheel, a 22mm tread, a plain bearing and a total height of 100mm, this light duty top plate castor fits easily with its 60 x 60mm top plate and suits retail displays, workshop equipment and storage units.
Why Choose This Castor
- ✓ Swivel design for easy turning in confined spaces
- ✓ 70mm swivel radius for sharp, tidy turns
- ✓ Black polypropylene wheel, lightweight yet durable and resistant to wear
- ✓ 75kg load capacity per castor for moderate loads
- ✓ 22mm tread width for stability and balance
- ✓ 60 x 60mm top plate with 48/38mm hole centres for flexible fitting
* Load capacity is per castor. For safe use, choose castors whose combined rating comfortably exceeds the weight of your equipment and its load.
Where It Works Best
- ✓ Retail displays: mobile display units that can be easily repositioned
- ✓ Workshops: moving tools and equipment around with minimal effort
- ✓ Storage solutions: moving storage racks and containers within warehouses
Frequently Asked Questions
Does this castor swivel?
Yes. It swivels a full 360 degrees with a 70mm swivel radius, so your trolley or unit turns easily in tight spaces.
How much weight can it carry?
Each castor is rated at 75kg. Add up the rating of all the castors on your unit to find the total capacity.
What is the wheel made of?
The wheel is black polypropylene, which is lightweight yet durable and resists wear.
How is the castor fitted?
It has a 60 x 60mm top plate with 6mm holes on 48/38mm hole centres, which you bolt to the underside of your trolley, display or cabinet.
How tall is the castor?
The total castor height is 100mm.
* This product does not have free shipping.
