- Load per castor350 kg
- Wheel diameter160 mm
- Overall height200 mm
- WheelNylon
- Secure checkout
- 14-day returns on unused items
- UK-based castor advice
Specifications
- Castor Type
- Top Plate Castors
- Bearing Type
- Roller
- Load Capacity
- 350 kg
- Tread Width
- 40 mm
- Temperature Range
- -40°C to +80°C
- Hardness of Tread
- D75
- Max Load Capacity of 4 Castors
- 1050 kg
- Plate Length
- 137 mm
- Plate Width
- 105 mm
- Plate Hole Centres Length
- 105 mm
- Plate Hole Centres Width
- 80/75 mm
- Plate Hole Diameter
- 10 mm
- Swivel Radius
- 140 mm
- Total Castor Height
- 200 mm
- Wheel Colour
- White
- Wheel Diameter
- 160 mm
- Wheel Material
- Nylon
Will it fit?
- Top plate137 mm × 105 mm
- Hole centres105 mm × 80/75 mm
- Fixing holeØ 10 mm
- Overall height200 mm
- Swivel radius140 mm
Replacing an old castor? Measure between the centres of two fixing holes along the long edge, then across the short edge, and compare with the hole centres above. Allow the swivel radius as clear space around each castor so it can turn freely.
Load check
How we work it out: on a real floor one castor is often carrying little or nothing, so we share the weight across one fewer castor than you fit (with 3 castors, across all 3). Tick the box to add a 30% margin for rough use.
Floors & use
Nylon / polypropylene wheel · working temperature -40°C to +80°C
- Very easy to push, even when loaded
- Resists water, oil and many chemicals
- Hard-wearing and easy to wipe clean
- Best on smooth concrete and hard floors
- Noisier than rubber or polyurethane
- Hard tread can mark or damage soft and delicate floors
- Rolls poorly over debris and cables
Details & FAQs
This 160mm directional lock castor is designed for precise movement and stability in various applications. Featuring a robust white nylon wheel, it is perfect for equipment requiring controlled directionality and smooth operation. With a load capacity of up to 350kg, this castor is ideal for warehouse trolleys, industrial carts, hospital equipment, and retail display units.
Applications
- Warehouse Trolleys: Ensures controlled movement and stability.
- Industrial Carts: Provides directional control in material handling.
- Hospital Equipment: Facilitates precise positioning and movement.
- Retail Display Units: Enhances easy manoeuvrability and positioning.
Frequently Asked Questions
- What is the load capacity of this castor? The load capacity is 350kg.
- What surfaces is the nylon wheel suitable for? The nylon wheel is designed for smooth surfaces.
- What temperature range can this castor operate in? It can operate in temperatures ranging from -40°C to +80°C.
- How is this castor mounted? It is mounted via a top plate.
- What is the swivel radius of this castor? The swivel radius is 140mm.
- Can this castor be used in hospitals? Yes, it is ideal for hospital equipment requiring precise movement.
Premium Quality Castor Solution
Engineered for reliability, designed for performance, built to protect your floors and enhance mobility in professional environments.
