- Load per castor122 kg
- Wheel diameter63 mm
- Overall height81 mm
- WheelNylon
- Secure checkout
- 14-day returns on unused items
- UK-based castor advice
Specifications
- Castor Type
- Top Plate Castors
- Bearing Type
- Plain
- Load Capacity
- 122 kg
- Tread Width
- 22 mm
- Load Capacity Dynamic
- 122 kg
- Max Load Capacity of 4 Castors
- 366 kg
- Plate Length
- 95 mm
- Plate Width
- 59 mm
- Plate Hole Centres Length
- 76 mm
- Plate Hole Centres Width
- 35 mm
- Plate Hole Diameter
- 8 mm
- Total Castor Height
- 81 mm
- Wheel Colour
- White
- Wheel Diameter
- 63 mm
- Wheel Material
- Nylon
Will it fit?
- Top plate95 mm × 59 mm
- Hole centres76 mm × 35 mm
- Fixing holeØ 8 mm
- Overall height81 mm
Replacing an old castor? Measure between the centres of two fixing holes along the long edge, then across the short edge, and compare with the hole centres above. Allow the swivel radius as clear space around each castor so it can turn freely.
Load check
How we work it out: on a real floor one castor is often carrying little or nothing, so we share the weight across one fewer castor than you fit (with 3 castors, across all 3). Tick the box to add a 30% margin for rough use.
Floors & use
Nylon / polypropylene wheel
- Very easy to push, even when loaded
- Resists water, oil and many chemicals
- Hard-wearing and easy to wipe clean
- Best on smooth concrete and hard floors
- Noisier than rubber or polyurethane
- Hard tread can mark or damage soft and delicate floors
- Rolls poorly over debris and cables
Details & FAQs
The 63 mm fixed castor features a robust white nylon wheel, engineered for stable and controlled movement of light to medium-duty loads across industrial, commercial, and workshop environments. With a load capacity of up to 122 kg per castor, it is ideal for applications such as trolleys, storage units, workbenches, and mobile equipment where reliability and directional stability are paramount.
Applications
This versatile castor is commonly used in:
- Industrial and warehouse trolleys
- Storage and handling equipment
- Workbenches and mobile units
- Light to medium-duty machinery
Frequently Asked Questions
Q: What is the load capacity of this castor?
A: The load capacity is 122 kg per castor.
Q: What type of surfaces is this castor suitable for?
A: It is designed for smooth surfaces, providing low rolling resistance.
Q: Can this castor be used for outdoor applications?
A: While it is primarily designed for indoor use, it may be used outdoors on smooth surfaces.
Q: Is this castor suitable for heavy-duty applications?
A: This castor is best suited for light to medium-duty applications.
Q: How is the castor mounted?
A: The castor features a top plate design for easy mounting.
Q: What material is the wheel made from?
A: The wheel is made from durable nylon, ensuring longevity and resistance to wear.
Premium Quality Castor Solution
Engineered for reliability, designed for performance, built to protect your floors and enhance mobility in professional environments.
