- Load per castor600kg per castor
- Wheel diameter250mm
- Overall height305mm
- WheelBlack super elastic rubber tyre on pressed steel centre
- Secure checkout
- 14-day returns on unused items
- UK-based castor advice
Specifications
- Castor Type
- Heavy Duty Swivel Top Plate Castor with Directional Lock and Leading Brake
- Brake
- Foot-operated leading brake
- Directional Lock
- Foot-operated swivel lock
- Wheel Diameter
- 250mm
- Wheel Material
- Black super elastic rubber tyre on pressed steel centre
- Tread
- Ribbed
- Tread Width
- 85mm
- Bearing Type
- Ball bearing
- Fixing
- Top plate, 4 bolt holes
- Plate Size
- 175 x 140mm
- Hole Centres
- 140 x 105mm
- Hole Diameter
- 14mm
- Total Castor Height
- 305mm
- Load Capacity
- 600kg per castor
Load check
How we work it out: on a real floor one castor is often carrying little or nothing, so we share the weight across one fewer castor than you fit (with 3 castors, across all 3). Tick the box to add a 30% margin for rough use.
Floors & use
Thermoplastic / elastic tread
- Soft, quiet and smooth rolling
- Gentle on wood, laminate, vinyl and tiles
- Good shock absorption
- Not for high heat or very heavy loads
Details & FAQs
Super Elastic Rubber Castors
Built for big, heavy trolleys that need a soft, smooth ride, this heavy duty swivel castor has a large 250mm black super elastic rubber tyre with a ribbed tread on a pressed steel centre. Two foot pedals give you full control: the directional lock holds the swivel head straight so the castor runs like a fixed castor for easy straight-line pushing, and the leading brake holds the trolley still when it needs to stay put. The thick elastic rubber cushions bumps and rolls over uneven floors and outdoor surfaces with ease, while the ball bearing keeps rotation smooth. Each castor is rated for 600kg.
It fixes to your equipment with a 175 x 140mm top plate and stands 305mm tall. Check that the plate size and hole centres match your existing setup before ordering.
Why Choose This Castor
- ✓ 600kg load capacity per castor for heavy loads.
- ✓ Super elastic rubber tyre 250mm black tyre with a ribbed 85mm tread, cushioning shocks and running quietly.
- ✓ Large wheel rolls easily over cracks, thresholds and rough ground.
- ✓ Ball bearing for efficient rotation with less effort.
- ✓ Directional lock locks the swivel head straight for easy pushing over long runs.
- ✓ Leading brake foot-operated brake holds equipment securely in place.
- ✓ 175 x 140mm top plate with four 14mm holes on 140 x 105mm centres.
* Load capacity is per castor on a level surface. Check that the plate size, hole centres and swivel clearance suit your mounting area before fitting.
Where It Works Best
This heavy duty braked elastic rubber castor with directional lock suits:
- ✓ Industrial trolleys: moving heavy loads with ease.
- ✓ Warehouse equipment: equipment that needs a high load capacity.
- ✓ Material handling carts: smooth movement and strong support, indoors and outdoors.
Frequently Asked Questions
How much weight can this castor carry?
Each castor is rated for 600kg. Add up the castors under your equipment to work out the total load.
What is the wheel made of?
A 250mm black super elastic rubber tyre with a ribbed tread, fitted on a pressed steel centre and running on a ball bearing.
How is the castor fitted?
It has a 175 x 140mm top plate with four 14mm holes on 140 x 105mm hole centres, bolted flat to the underside of your trolley, cart or machine.
Can it be used outdoors?
Yes. The large elastic rubber tyre handles uneven ground, ramps and outdoor surfaces well and cushions the load as it rolls.
What does the directional lock do?
Press the lock pedal and the swivel head is held straight, so the castor runs like a fixed castor. This makes long straight pushes easier. Release it to swivel freely again.
Does this castor have a brake?
Yes. Press the brake pedal to hold your equipment in place and lift it to release. The total castor height is 305mm.
