- Load per castor200kg per castor *
- Wheel diameter125mm
- Overall height155mm
- WheelPolyurethane on Nylon
- Secure checkout
- 14-day returns on unused items
- UK-based castor advice
Specifications
- Castor Type
- Fixed Top Plate Castor
- Housing
- Stainless Steel
- Wheel Diameter
- 125mm
- Wheel Material
- Polyurethane on Nylon
- Wheel Colour
- Red
- Tread Width
- 23mm
- Tread Hardness
- D60
- Bearing Type
- Roller
- Load Capacity
- 200kg per castor *
- Top Plate Size
- 101 x 85mm
- Bolt Hole Centres
- 80 x 60mm
- Bolt Hole Diameter
- 8mm
- Total Castor Height
- 155mm
- Temperature Range
- -40°C to +80°C
Will it fit?
- Bolt hole80 x 60mm
- Overall height155mm
Replacing an old castor? Measure between the centres of two fixing holes along the long edge, then across the short edge, and compare with the hole centres above. Allow the swivel radius as clear space around each castor so it can turn freely.
Load check
How we work it out: on a real floor one castor is often carrying little or nothing, so we share the weight across one fewer castor than you fit (with 3 castors, across all 3). Tick the box to add a 30% margin for rough use.
Floors & use
Polyurethane tread · working temperature -40°C to +80°C
- Rolls quietly and smoothly
- Kind to most finished floors
- Hard-wearing, carries a high load for its size
- Ideal on concrete, epoxy, vinyl and tiles
- Not intended for very hot areas
- Less cushioning than rubber over rough ground
Details & FAQs
Stainless Steel Fixed Castor
This 125mm stainless steel fixed castor runs on a red polyurethane on nylon wheel, carrying up to 200kg per castor. It is made for food manufacturing, warehouse operations and logistics, where heavy loads need stable, straight-line movement.
The D60 polyurethane tread resists wear and abrasion, the roller bearing reduces friction, and the stainless steel construction resists corrosion. The 101 x 85mm top plate has four 8mm holes for fixing to flat surfaces. It works from -40°C to +80°C.
Why Choose This Castor
- ✓ Stainless steel construction for corrosion resistance
- ✓ D60 polyurethane tread resists wear and abrasion
- ✓ Roller bearing for smooth movement and reduced friction
- ✓ 200kg load capacity per castor
- ✓ Wide -40°C to +80°C temperature range
- ✓ 101 x 85mm top plate with four 8mm holes
* Load capacity is per castor. For a set of four, allow for uneven floors by planning on three castors carrying the load.
Where It Works Best
- ✓ Food manufacturing, moving equipment and products in hygienic areas
- ✓ Warehouse operations that transport goods and materials
- ✓ Logistics and distribution with heavy loads on different surfaces
Need a different size? See our stainless steel fixed castor range.
Frequently Asked Questions
What is the wheel made of?
The wheel has a red D60 polyurethane tread on a nylon centre, which offers durability and resistance to abrasion.
Does a fixed castor swivel?
No, a fixed castor only rolls in a straight line. Many trolleys pair two fixed castors with two swivel castors for steering.
How much weight can it carry?
Each castor is rated at 200kg. A set of four is best used for loads up to around 600kg, allowing for uneven floors.
How is it fitted?
The 101 x 85mm top plate has four 8mm holes on 80 x 60mm centres. Bolt it flat to the underside of your trolley or equipment.
How tall is it?
The total castor height is 155mm, measured from the floor to the top plate.
What temperatures can it be used in?
The castor is suited to temperatures from -40°C to +80°C.
