- Load per castor350 kg
- Wheel diameter160 mm
- Overall height200 mm
- WheelElectrically Conductive Polyurethane
- Secure checkout
- 14-day returns on unused items
- UK-based castor advice
Specifications
- Castor Type
- Top Plate Castors
- Bearing Type
- Ball Bearing
- Load Capacity
- 350 kg
- Tread Width
- 40 mm
- Temperature Range
- -40°C to +80°C
- Hardness of Tread
- 95 shore A
- Max Load Capacity of 4 Castors
- 1050 kg
- Plate Length
- 140 mm
- Plate Width
- 110 mm
- Plate Hole Centres Length
- 105 mm
- Plate Hole Centres Width
- 80/75 mm
- Plate Hole Diameter
- 10 mm
- Swivel Radius
- 135 mm
- Total Castor Height
- 200 mm
- Wheel Colour
- Grey
- Wheel Diameter
- 160 mm
- Wheel Material
- Electrically Conductive Polyurethane
Will it fit?
- Top plate140 mm × 110 mm
- Hole centres105 mm × 80/75 mm
- Fixing holeØ 10 mm
- Overall height200 mm
- Swivel radius135 mm
Replacing an old castor? Measure between the centres of two fixing holes along the long edge, then across the short edge, and compare with the hole centres above. Allow the swivel radius as clear space around each castor so it can turn freely.
Load check
How we work it out: on a real floor one castor is often carrying little or nothing, so we share the weight across one fewer castor than you fit (with 3 castors, across all 3). Tick the box to add a 30% margin for rough use.
Floors & use
Polyurethane tread · working temperature -40°C to +80°C
- Rolls quietly and smoothly
- Kind to most finished floors
- Hard-wearing, carries a high load for its size
- Ideal on concrete, epoxy, vinyl and tiles
- Not intended for very hot areas
- Less cushioning than rubber over rough ground
Details & FAQs
This 160mm Electro Conductive Swivel Castor is expertly designed to safely dissipate static electricity, making it ideal for sensitive environments. Featuring a robust polyurethane wheel, this castor ensures smooth operation and stability, with a load capacity of 350kg per wheel. Perfect for applications in electronics manufacturing, laboratories, and data centres, this castor helps maintain a static-free environment for safe equipment movement.
Applications
This swivel castor is perfect for:
- Electronics Manufacturing: Prevents static build-up on sensitive equipment.
- Laboratories: Ensures safe movement in environments requiring electrostatic discharge control.
- Data Centres: Maintains static-free environments for equipment movement.
FAQs
- What is the load capacity of this castor? The load capacity is 350 kg per castor.
- What temperature range can this castor operate in? It can operate in temperatures ranging from -40°C to +80°C.
- Is this castor suitable for electronic equipment? Yes, it is designed to dissipate static electricity, making it ideal for sensitive electronic environments.
- What is the diameter of the wheel? The wheel diameter is 160 mm.
- What is the hardness rating of the wheel tread? The tread hardness is rated at 95 shore A.
- Can this castor swivel? Yes, it features a swivel radius of 135 mm for enhanced maneuverability.
Premium Quality Castor Solution
Engineered for reliability, designed for performance, built to protect your floors and enhance mobility in professional environments.
