Mini Index Plunger M7 - 20mm Length, 7mm Plunger Height

Mini Index Plunger M7 is designed for precision in thin-walled applications.

This compact and robust plunger is perfect for secure fastening and positioning in thin materials, making it an essential tool in industrial settings. Its thoughtful design ensures compatibility and ease of operation, even in tight spaces.

Key Features

• Base Nut Height: 12mm – Provides a stable foundation for the plunger, enhancing its reliability during use.
• Base To Thread Height: 2mm – Optimises the design for thin-walled applications, ensuring a perfect fit.
• Handle Diameter: 14mm – Offers a comfortable grip for easy operation, even in tight spaces.
• Length: 20mm – Compact size makes it suitable for applications with limited space.
• Overall Plunger Height: 20mm – Ensures adequate reach for effective engagement with materials.
• Plunger Height: 7mm – Provides sufficient depth for secure fastening in thin materials.
• Thread Size: M7 – Compatible with standard fittings, allowing for versatile use in various applications.

Specifications

• Material: Steel
• Finish: Zinc-plated
• Operating Temperature: -20°C to 80°C
• Load Capacity: Up to 1000N

Applications

• Thin-walled metal fabrication
• Assembly of lightweight structures
• Automotive interior components
• Electronics housing
• Furniture assembly
